Timestrip neo
a new generation of electronic indicator
Electronic time & temperature indicator technology for pack level monitoring. Very small and light weight, good accuracy with low cost.
Contact us
Electronic Temperature indicators
Indicator
Breach time
Size
Used in
Fridge -0.5ºC, 2ºC-8ºC
TT525-AB
8ºC for 8 Hours
22.6mm x 42.3mm x 5.6mm
Vaccines, Pharma, Food
Freeze Alarm 0ºC
TT525-AD
30 Minutes & 60 Minutes
22.6mm x 42.3mm x 5.6mm
Vaccines, Pharma, Adhesives
Room Temp 15-25ºC
TT525-AE
Below 15ºC, Above 25ºC
22.6mm x 42.3mm x 5.6mm
Pharma, Vaccines
Electronic Time Temperature Technology
Featuring
- Small, micro-weight indicator, suitable for many monitoring tasks
- Clear irreversible alarm indication
- Tolerant of extreme heat and cold
- No training required
- Long shelf life and operation time
- Available from stock, but with customised options for time and temperature
- Cost effective solution for supply chain monitoring
Timestrip neo Applications
- Temperature monitoring of drugs and vaccines
- Shelf-life monitoring with temperature excursion alerts
- Pharmaceutical package level monitoring
- Clinical trial samples monitoring
- High value goods, sensitive foodstuffs, etc.
- Adhesives, paints and chemicals
Full Cold Chain Coverage
Stock Timestrip neo indicators cover a wide range of cold chain monitoring
Freeze Alarm
- Designed for products that are sensitive to freezing
- Visible alert if the ambient temperature drops below 0°C for 30 minutes
- Second LED shows a further alarm at 60 minutes below 0°C
Fridge Alarm
- Reacts at three temperatures and five time intervals
- Visible alert if the temperature drops below 2°C
- Second LED shows a further alarm if the temperature drops below -0.5°C
- Row of 3 LEDs alert when the product has been above 8°C for 2,4,6 and 8 hours
Room Temp Alarm
- Designed for products that are shipped and stored at room temperature
- Visible alert if the ambient temperature drops below 15°C for 60 minutes
- Second LED shows an alarm if the ambient temperature rises above 25°C for 60 minutes
Can't find what you need?
Our stock Timestrip neo covers 3 important ranges of cold chain temperatures. If you don't see the range you need, we can customise Timestrip neo to your exact specifications. The stock Timestrip neo is not a Time Temperature Indicator (TTI), but you can choose to add TTI as a custom option.
Contact us to find out more.
Want to learn more?
Please fill out this form to find out how TImestrip neo can help you monitor multiple temperature excursions, request more information, or order.
Timestrip neo Documentation
Standard Timestrip neo Specifications
Type
Single use, nonreversible
Size
22.6mm x 42.3mm x 5.6mm ; 6g
Activation Feature
Rigid plastic
Activation Feature
Hold button for 3.5 seconds
Sensor
Internal NTC
Service Life
1 year
Shelf Life
2 years
Environmental
IP54
Stock Timestrip neo TT525-AB Specifications
Temperature Breach
10 minute below -0.5ºC
30 minute below 2ºC
8 hours cumulative above 8ºC
30 minute below 2ºC
8 hours cumulative above 8ºC
Start Delay
30 minutes
Temperature Sample Rate
32 seconds
LED alarm
Over 8ºC for 2, 4, 6, 8 hours
Under 2ºC for 30 minutes
Under -0.5ºC for 10 minutes
Under 2ºC for 30 minutes
Under -0.5ºC for 10 minutes
Stock Timestrip neo TT525-AD Specifications
Temperature Breach
Single event under 0ºC for 30 minutes
Single event under 0ºC for 60 minutes
Single event under 0ºC for 60 minutes
Start Delay
30 minutes
Temperature Sample Rate
32 seconds
LED alarm
Power On
Under 0ºC for 30 Minutes
Under 0ºC for 60 Minutes
Under 0ºC for 30 Minutes
Under 0ºC for 60 Minutes
Stock Timestrip neo TT525-AE Specifications
Temperature Breach
Single event under 15ºC for 60 minutes
Single event over 25ºC for 60 minutes
Single event over 25ºC for 60 minutes
Start Delay
30 minutes
Temperature Sample Rate
32 seconds
LED alarm
Power on
Over 25ºC for 60 mintues
Under 15ºC for 60 minutes
Over 25ºC for 60 mintues
Under 15ºC for 60 minutes
